Old 12-11-2012, 12:30 PM   #1 (permalink)
Supporting Vendor

werks's Avatar

Join Date: Dec 2005
Location: Midwest
Send a message via Yahoo to werks
WERKSracing WR-3 Turbocharger official release!!!

We are proud to release our newest bolt-on LNF turbocharger, the WERKSracing WR-3! The WR-3 is our next iteration of our popular WR Series bolt on LNF turbochargers and supports up to 525whp!!!



Pictured Above - Optional Compressor housing powder coating, Forge Bypass valve and Type-S 4" inlet 2.5" outlet compressor housing option.

Features -

Stock appearing exhaust housing for a completely bolt on upgrade!!!
Supports up to 525hp!!!
Exhaust side Black Ceramic Coating included in price!!!
Core exchange program
Quick spool and response
55mm leading edge technology billet aluminum compressor wheel
56.5mm exhaust turbine wheel
Internal WG actuator included
Comes complete with all necessary lines and fittings
Compressor housing powdercoating = $50.00

LNF Cobalt SS on 93 octane dyno -


1 year warranty from the date of purchase

2-3 week current build time.

Purchase your WR-3 turbocharger here - The Home of WERKSracing products!
__________________
Dave Gilbert #475 Pontiac Solstice GXP Coupe NASA TTB 2012 Midwest Season Champion
Performance Autowerks, Inc.
Phone - 815-439-4547

Kappa LNF Engine - WERKSracing EFR 6758 kit - 431whp/478ftlbs
Kappa LE5 Engine - WERKSracing '50 trim" Turbo Kit - 374whp/358ftlbs
Kappa WERKSracing LS3 Edelbrock E-Force Supercharged Engine Conversion- 531whp/490ftlbs

www.performanceautowerks.com
info@performanceautowerks.com

Last edited by werks; 12-16-2012 at 10:37 AM.
werks is offline   Reply With Quote Quick reply to this message
Sponsored Links
Advertisement

Old 12-11-2012, 12:51 PM   #2 (permalink)
Moderator

rob the elder's Avatar

Join Date: Nov 2007
Location: Parker Colorado, USA, directly above the center of the earth
A very nice looking product. But it needs to be RED.
__________________
Rob the Elder

Punisher's Daddy
Green Dragon's chief mechanic
Carol's husband for 45 years

Secretary Rocky Mountain Solstice and Sky Club
Punisher's story
http://www.solsticeforum.com/forum/f62/punisher-65168/
http://www.skyroadster.com/forums/f2...cussion-42115/

rob the elder is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 01:12 PM   #3 (permalink)
Member

Join Date: Jul 2009
Forget what color it is, I'd like to see some Dyno's
__________________
2007 Sky Redline: DDMWorks Charge Pipes & Intercooler, Solo Performance 3" Mach Shorty, ZZP S1 cams, Supertech Valve springs, BNR 2871, SPEC Stage 3+, Android "Torque" bluetooth RPD, HPT e47 tuned by TERM2. ???whp ???wtrq Dyno coming soon.
40rty is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 04:38 PM   #4 (permalink)
Supporting Vendor

werks's Avatar

Join Date: Dec 2005
Location: Midwest
Send a message via Yahoo to werks
Quote:
Originally Posted by rob the elder View Post
A very nice looking product. But it needs to be RED.
Thank you Rob and yes we can do one in Red, that is not a problem!
__________________
Dave Gilbert #475 Pontiac Solstice GXP Coupe NASA TTB 2012 Midwest Season Champion
Performance Autowerks, Inc.
Phone - 815-439-4547

Kappa LNF Engine - WERKSracing EFR 6758 kit - 431whp/478ftlbs
Kappa LE5 Engine - WERKSracing '50 trim" Turbo Kit - 374whp/358ftlbs
Kappa WERKSracing LS3 Edelbrock E-Force Supercharged Engine Conversion- 531whp/490ftlbs

www.performanceautowerks.com
info@performanceautowerks.com
werks is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 04:39 PM   #5 (permalink)
Supporting Vendor

werks's Avatar

Join Date: Dec 2005
Location: Midwest
Send a message via Yahoo to werks
Quote:
Originally Posted by 40rty View Post
Forget what color it is, I'd like to see some Dyno's
We will be posting up some numbers shortly. I am dyno tuning this gold turbo on a Cobalt Thursday afternoon.
__________________
Dave Gilbert #475 Pontiac Solstice GXP Coupe NASA TTB 2012 Midwest Season Champion
Performance Autowerks, Inc.
Phone - 815-439-4547

Kappa LNF Engine - WERKSracing EFR 6758 kit - 431whp/478ftlbs
Kappa LE5 Engine - WERKSracing '50 trim" Turbo Kit - 374whp/358ftlbs
Kappa WERKSracing LS3 Edelbrock E-Force Supercharged Engine Conversion- 531whp/490ftlbs

www.performanceautowerks.com
info@performanceautowerks.com
werks is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 04:47 PM   #6 (permalink)
Member

Alan_L's Avatar

Join Date: Sep 2008
Location: Albuquerque NM
Just for comparison sake, what are the specs on the stock turbo? Also, I am thinking really hard about getting this on my car in the spring time with some other minor supporting mods, what kind of power is safe on a stock engine?
Alan_L is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 10:27 PM   #7 (permalink)
Supporting Vendor

mkriebs's Avatar

Join Date: Aug 2009
Quote:
Originally Posted by Alan_L View Post
Just for comparison sake, what are the specs on the stock turbo? Also, I am thinking really hard about getting this on my car in the spring time with some other minor supporting mods, what kind of power is safe on a stock engine?
Stock motor in a Solstice on our dyno we have been over 400 quite a few times. I recommend some valve springs and having Dave tune it and you should be good to go (depending on the fuel you have access to).
__________________
Performance AutoWerks
Matt Kriebs - Sales Rep
www.performanceautowerks.com
www.werksracing.net

PM me for all your WERKS Racing parts needs!
mkriebs is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 10:53 PM   #8 (permalink)
Member

Slik's Avatar

Join Date: Apr 2011
Location: Los Angeles
looking at it, do we need the type-s housing and the forge bypass valve? not trying to stray anyone from getting them, but im just curious as to what the benefits are and/or if it would need to have it to be installed correctly
__________________
07 Mean Solstice GXP (Auto)
20" Rims - Staggered
Debadged
Antenna Delete
Eibach Sportlines 2" Drop

Future Mods:
Trifecta Tune
Solo Performance Street-Race
Hahn Intercooler

Last edited by Slik; 12-11-2012 at 11:20 PM.
Slik is offline   Reply With Quote Quick reply to this message
Old 12-11-2012, 11:46 PM   #9 (permalink)
Member

Join Date: Jul 2009
Quote:
Originally Posted by Alan_L View Post
Just for comparison sake, what are the specs on the stock turbo? Also, I am thinking really hard about getting this on my car in the spring time with some other minor supporting mods, what kind of power is safe on a stock engine?
Here are the specs for the k04(ignore the BNR 2871 specs)



Anything passed the 400hp mark can put piston rings at risk.


Quote:
Originally Posted by Slik View Post
looking at it, do we need the type-s housing and the forge bypass valve? not trying to stray anyone from getting them, but im just curious as to what the benefits are and/or if it would need to have it to be installed correctly
Not sure about the Type-s housing, I'm sure Werks can dive into that. The reason though for the Forge bypass valve design is because its the most efficient way to expel air from the system. Remember these were designed to bring you a package similar to what the EFR series offers. There is a shortage from BW so Werk's(and correct me if I'm wrong) wanted to provide a product that was readily available but along the same lines using Precision components which are pure sex btw. Good company
__________________
2007 Sky Redline: DDMWorks Charge Pipes & Intercooler, Solo Performance 3" Mach Shorty, ZZP S1 cams, Supertech Valve springs, BNR 2871, SPEC Stage 3+, Android "Torque" bluetooth RPD, HPT e47 tuned by TERM2. ???whp ???wtrq Dyno coming soon.
40rty is offline   Reply With Quote Quick reply to this message
Old 12-12-2012, 01:10 AM   #10 (permalink)
Member

Slik's Avatar

Join Date: Apr 2011
Location: Los Angeles
Quote:
Originally Posted by 40rty View Post



Not sure about the Type-s housing, I'm sure Werks can dive into that. The reason though for the Forge bypass valve design is because its the most efficient way to expel air from the system. Remember these were designed to bring you a package similar to what the EFR series offers. There is a shortage from BW so Werk's(and correct me if I'm wrong) wanted to provide a product that was readily available but along the same lines using Precision components which are pure sex btw. Good company
so in ur opinion 40rty would it be better for the actual "bypass valve" or for the air to "vent to the atmosphere" (the options they are giving)?
__________________
07 Mean Solstice GXP (Auto)
20" Rims - Staggered
Debadged
Antenna Delete
Eibach Sportlines 2" Drop

Future Mods:
Trifecta Tune
Solo Performance Street-Race
Hahn Intercooler
Slik is offline   Reply With Quote Quick reply to this message
Old 12-12-2012, 01:25 AM   #11 (permalink)
Member

Join Date: Jul 2009
Well, for a engine like ours that runs on metered air measurement, a Bypass valve will be more than sufficient for something sticking to stock turbo and even upgrades such as the WR-3 and similar. BOV do have their place in high horse power applications and where tuning will allow for a readjustment of the tune to support the BOV.
__________________
2007 Sky Redline: DDMWorks Charge Pipes & Intercooler, Solo Performance 3" Mach Shorty, ZZP S1 cams, Supertech Valve springs, BNR 2871, SPEC Stage 3+, Android "Torque" bluetooth RPD, HPT e47 tuned by TERM2. ???whp ???wtrq Dyno coming soon.
40rty is offline   Reply With Quote Quick reply to this message
Old 12-12-2012, 01:37 AM   #12 (permalink)
Member

Slik's Avatar

Join Date: Apr 2011
Location: Los Angeles
thanks for the clarification!
__________________
07 Mean Solstice GXP (Auto)
20" Rims - Staggered
Debadged
Antenna Delete
Eibach Sportlines 2" Drop

Future Mods:
Trifecta Tune
Solo Performance Street-Race
Hahn Intercooler
Slik is offline   Reply With Quote Quick reply to this message
Old 12-12-2012, 07:34 AM   #13 (permalink)
Member

Alan_L's Avatar

Join Date: Sep 2008
Location: Albuquerque NM
And is that 400 wheel or crank?
Alan_L is offline   Reply With Quote Quick reply to this message
Old 12-12-2012, 07:58 AM   #14 (permalink)
Member

Join Date: Jul 2012
Location: Carol Stream IL
we use a lot of percision stuff and its been proven great throughout the racing world in all applications. they are number 1 in my books. the only borg turbo i personally like is the efr series. to each is their own though.

we built this to add to the world of having a bolt on turbo. zzp already did the zfr and we werent going to copy it. the percision stuff is no slouch and has just as many great features such as the efr does. we made it work with a stock type setup integrating the breather and also the stock style bov.

we recommend the forge unit for this turbo as well as the wr2. with the wr3 i would say its needed. also the anti surge cover isnt 100% needed but its a good thing to have imho. any time you can recirculate that air in, its beneficial to you. the wr3 is pretty massive.
Omiotek is offline   Reply With Quote Quick reply to this message
Old 12-12-2012, 08:45 AM   #15 (permalink)
Supporting Vendor

mkriebs's Avatar

Join Date: Aug 2009
Quote:
Originally Posted by Alan_L View Post
And is that 400 wheel or crank?
To the wheels. It really all depends on the tune on how long everything will last. I know guys who had joe blow tune the car and it blew up at 300 whp, that's why I said have Dave tune it. He's been around the block a couple times with the LNF and if you look in his sig, those numbers prove he knows whats up.
__________________
Performance AutoWerks
Matt Kriebs - Sales Rep
www.performanceautowerks.com
www.werksracing.net

PM me for all your WERKS Racing parts needs!
mkriebs is offline   Reply With Quote Quick reply to this message
